Description
Specifications
- Total Cores: 4
- Total Threads: 8
- Max Turbo Frequency: 4.40 GHz
- Intel® Turbo Boost Technology 2.0 Frequency‡: 4.40 GHz
- Processor Base Frequency: 4.00 GHz
- Cache: 8 MB Intel® Smart Cache
- Bus Speed: 5 GT/s
- TDP: 88 W
- Supplemental Information
- Marketing Status: Discontinued
- Launch Date: Q2'14
- Embedded Options Available: No
- DatasheetView now
- Memory Specifications
- Max Memory Size (dependent on memory type) 32 GB
- Memory Types DDR3-1333/1600, DDR3L-1333/1600 @ 1.5V
- Max # of Memory Channels 2
- Max Memory Bandwidth 25.6 GB/s
- ECC Memory Supported ‡ No
- GPU Specifications
- GPU Name‡ Intel® HD Graphics 4600
- Graphics Base Frequency 350 MHz
- Graphics Max Dynamic Frequency 1.25 GHz
- Graphics Video Max Memory 2 GB
- Graphics Output eDP/DP/HDMI/DVI/VGA
- Execution Units 20
- Max Resolution (HDMI)‡ 3840x2160@24Hz
- Max Resolution (DP)‡ 3840x2160@60Hz
- Max Resolution (eDP - Integrated Flat Panel)‡ 3840x2160@60Hz
- Max Resolution (VGA)‡ 1920x1200@60Hz
- DirectX* Support 11.2/12
- OpenGL* Support 4.3
- Intel® Quick Sync Video Yes
- Intel® InTru™ 3D Technology Yes
- Intel® Flexible Display Interface (Intel® FDI) Yes
- Intel® Clear Video HD Technology Yes
- # of Displays Supported ‡3
- Device ID0x412
- Expansion Options
- Scalability1S Only
- PCI Express Revision 3.0
- PCI Express Configurations ‡ Up to 1x16, 2x8, 1x8+2x4
- Max # of PCI Express Lanes 16
- Package Specifications
- Sockets Supported FCLGA1150
- Max CPU Configuration1
- Thermal Solution Specification PCG 2013D
- TCASE 74.04°C
- Package Size37.5mm x 37.5mm
- Advanced Technologies
- Intel® Turbo Boost Technology ‡ 2.0
- Intel® Hyper-Threading Technology ‡ Yes
- Intel® Transactional Synchronization Extensions No
- Intel® 64 ‡ Yes
- Instruction Set 64-bit
- Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
- Intel® My WiFi Technology Yes
- Idle States Yes
- Enhanced Intel SpeedStep® Technology Yes
- Thermal Monitoring Technologies Yes
- Intel® Identity Protection Technology ‡ Yes
- warranty : 30 days
