Specifications
-
Video & Audio
- IP Video Input: 16-ch (up to 32-ch), each up to 8MP
- Analog Video Input: 16-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- Video Live: 8MP (4K)
- Video Recording: 5MP
- Video Input Types: HDTVI/AHD/CVI/CVBS/IP
- VGA Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- HDMI Output: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- Audio Input: 1-ch (up to 16-ch is optional), RCA (2.0 Vpp,1 KΩ),16-ch via coaxial cable
- Audio Output: 1-ch, RCA (Linear, 1 KΩ)
-
Recording
- Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
-
Frame Rate: Main Stream: 8 MP@8 fps/3K@12 fps/5 MP@12 fps/4 MP@15 fps/8 MP Lite@15 fps/3 MP@18 fps, 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N), Sub-stream: WD1/4CIF/CIF@25 fps (P)/30 fps (N)
- Video Bitrate: 32 Kbps to 10 Mbps
- Stream Type: Video, Video & Audio
- Audio Bitrate: 64 Kbps
-
Network
- Network Interface: 1x RJ45 10/100/1000 Mbps self-adaptive Ethernet interface
- Total Bandwidth: 256Mbps
- Remote Connection: 128
-
Interface
- HDD Type: 2x SATA
- Capacity: Up to 12TB Capacity for Each Disk
- Serial: RS-485 (half-duplex)
- USB: Front panel: 1× USB 2.0, Rear panel: 2× USB 3.0
-
General
- Operating Temperature: -10 °C to 55 °C (14 °F to +131 °F)
- Operating Humidity: 10% to 90%
- Power Supply: 12 VDC, 5 A
- Power Consumption: ≤ 60 W
- Dimensions (W × D × H): 385 x 315 x 52mm
- Weight: ≤ 2.1 kg
-
Warranty: 1 Year
