Description
TL-WA801ND 300Mbps Wireless N Access Point
- 300Mbps wireless speed ideal for smooth HD video, voice streaming and online gaming
- Supports multiple operation modes: Access Point, Multi-SSID, Client, Repeater, Bridge with AP
- Easily setup a WPA encrypted secure connection at a push of the WPS button
- Up to 30 meters (100 feet) of flexible deployment with included Passive Power over Ethernet Injector
Specifications:
HARDWARE FEATURES
- Interface
- One 10/100M Ethernet Port(RJ45)
- Support Passive PoE
- Button
- Power On/Off Button
- WPS Button
- Reset Button
- External Power Supply
- 9VDC / 0.6A
- Wireless Standards
- IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
- Dimensions ( W x D x H )
- 7.1 ×4.9× 1.4 in. (181 ×125 ×36mm)
- Antenna Type
- 2*5dBi Detachable Omni Directional (RP-SMA)
WIRELESS FEATURES
- Frequency
- 2.4-2.4835GHz
- Signal Rate
- 11n: Up to 300Mbps(dynamic)
- 11g: Up to 54Mbps(dynamic)
- 11b: Up to 11Mbps(dynamic)
- Reception Sensitivity
- 270M: -68dBm@10% PER
- 130M: -68dBm@10% PER
- 108M: -68dBm@10% PER
- 54M: -68dBm@10% PER
- 11M: -85dBm@8% PER
- 6M: -88dBm@10% PER
- 1M: -90dBm@8% PER
- Transmit Power
- <20dBm(EIRP)
- Wireless Modes
- AP Mode
- Multi-SSID Mode
- Client Mode
- Repeater Mode
- Bridge with AP Mode
- Wireless Functions
- Enable/Disable Wireless Radio
- MAC Address Filter
- Wireless Security
- 64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK
- Quality of Service
- WMM
- Management
- SNMP
- Advanced Functions
- Up to 30 meters Passive PoE is supported
- Warranty: 1 year
