Description
Specifications
- Printing
- Resolution: 203 DPI
- Printing method : Direct Thermal
- Max.print speed: Max. 70mm (2.7") / s
- Max.print width :72 mm (2.8")
- Max.print length :1778 mm (70")
- Media
- Media type : Continuous, gap, black mark
- Media width :20 mm ~ 76 mm
- Media thickness: 0.06 mm ~0.254 mm
- Label roll diameter : 50 mm
- Performance
- Processor : 32-bit CPU
- Memory :8MB Flash
- Interface
- Stardard version: USB+Bluetooth (Optional:USB+WIFI)
- Screen
- OLED (0.96") Resolution:128*64 pix
-
Sensors
Gap sensor
Cover opening sensor
Black mark sensor -
Fonts/Graphics/Symbologies
Internal fonts: 8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software. - 1D bar code: Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST
-
2D bar code : PDF-417, Maxicode, DataMatrix, QR code, Aztec
Rotation :0°、90°、180°、270°
Emulaion :TSPL、EPL、ZPL、DPL、CPCL、ESC/POS - Physical
- Dimension : 124 × 108 × 61mm (D×W×H)
- Weight :357 g
- Reliability
- Print head life : 30 km
- Software
- Operation system : Windows/Android/iOS
- SDK: Windows/Android/iOS
- Power supply
- Power input : DC 5V / 2A
- Battery : 7.2V / 2550mAh
- Environmental Conditions
- Operation environment :5 ~ 40°C（41~104°F），Humidity: 25 ~ 85% no condensing
- Storage environment -40 ~ 60°C（-40~140°F），Humidity: 10 ~ 90% no condensing
- warranty : 1 year
