Description
Specification
Camera
- Image Sensor : 3K CMOS
- Signal System : PAL/NTSC
- Mic : Built-in mic
- Resolution : 2960 (H) × 1665 (V)
- Frame Rate:
- TVI: 3K@20fps, 4 MP@25fps/30fps, 1080p@25fps/30fps
- AHD: 5 MP@20fps, 4 MP@25fps/30fps
- CVI: 4 MP@25fps/30fps
- CVBS: PAL/NTSC
- Min. Illumination : 0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter Time :- PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Lens
- 2.8 mm, 3.6 mm fixed focal lens
- Field Of View :
- 2.8 mm, horizontal FOV: 102°, vertical FOV: 56°, diagonal FOV: 122°
- 3.6 mm, horizontal FOV: 80°, vertical FOV: 45°, diagonal FOV: 96°
- Lens Mount : M12
- Light Alarm : Solid Light Alarm (White Light)
- Day & Night : 24/7 Color Imaging
- WDR (Wide Dynamic Range) : Digital WDR
- Angle Adjustment : Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
- White Light : Auto/Off
- Image Mode : STD/HIGH-SAT/HIGHLIGHT
- AGC : Yes
- Day/Night Mode : Color
- White Balance : Auto/Outdoor/Global/Manual
- AE (Auto Exposure) Mode : BLC;HLC;Global;HLS;DWDR
- Noise Reduction : 2D DNR
- Language : English
- Function : Defective Pixel Correction;Sharpness;Mirror;Contrast;Brightness;Anti-Banding;Smart Light
Interface
- Video Output : Switchable TVI/AHD/CVI/CVBS
General
- Operating Conditions : -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
- Power Supply :
- 12 VDC ± 25%,
- -<You are recommended to use one power adapter to supply the power for one camera.
- Consumption : Max. 2.5 W
- Material : Plastic
- White Light Range : Up to 20 m
- Communication : HIKVISION-C
- Dimension : Φ 85.02 mm × 81.25 mm (Φ 3.35" × 3.2")
- Weight : Approx. 165.5 g (0.36 lb.)
- warranty: 1 year
