Description
Specifications
- IP Video Input : 4-ch Up to 6 MP resolution
- Incoming Bandwidth : 40 Mbps
- Outgoing Bandwidth : 60 Mbps
- HDMI Output : 1-ch, 1920 × 1080p/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
- VGA Output : 1-ch, 1920 × 1080p/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
- Video Output Mode : HDMI/VGA simultaneous output
- Decoding
- Decoding Format: H.265+/H.265/ H.264+/H.264
- Recording Resolution : 6 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
- Synchronous playback : 4-ch
- Decoding Capability: 4-ch@1080p (30 fps) or 2-ch@4 MP (30 fps) or 1-ch@6 MP (30 fps)
- Stream Type : Video, Video & Audio
- Network:
- Remote Connection : 16
- Network Protocol : TCP/IP, DHCP, HiLookVision, DNS, DDNS, NTP, SADP, SMTP, UPnP™
- Network Interface : 1, RJ-45 10/100Mbps self-adaptive Ethernet interface
- Auxiliary Interface:
- SATA : 1 SATA interface
- Capacity : Up to 6 TB capacity for each disk
- Alarm : In/Out N/A
- USB Interface Rear panel: 2 × USB 2.0
- General:
- Power Supply: 12 VDC, 1.5 A
- Consumption : ≤ 10 W (without HDD)
- Working Temperature : -10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity : 10% to 90%
- Dimension : (W × D × H) 265 × 225 × 48 mm (10.4" × 8.9" × 1.9")
- Weight : ≤ 1 kg (without HDD, 2.2 lb.)
- warranty : 1 year
