Description
- Eliminate weak signal areas with whole home WiFi coverage.
- 2.4 GHz (300 Mbps) and 5 GHz (867 Mbps) dual-band WiFi connection ensures more stable wireless experience.†
- Creates a Mesh network by connecting to a TP-Link OneMesh™ router for seamless whole-home coverage.‡
- Adaptive Path Selection – connects to the fastest connection path to the router automatically and runs at top-speed.
- High Speed Mode – maximizes speed by using one WiFi band as dedicated backhaul, ideal for HD streaming and gaming.
- AP Mode – create a new Wi-Fi access point to enhance your wired network with Wi-Fi capability.
- Smart signal indicator helps to find the best location for optimal Wi-Fi coverage by showing the signal strength.
- Push the WPS button to easily connect to the router and you can uniformly manage from the Tether app or Web UI.
- Works with any Wi-Fi router or wireless access point
Specifications
WIRELESS:
Working Modes:
- Range Extender/Access Point
HARDWARE FEATURES:
Interface:
- 1 x 10/100M Ethernet Port (RJ45)
Ports:
- 1 x 10/100Mbps Ethernet Port (RJ45)
Button:
- WPS Button, Reset Button
Input Power:
- 100-240V~50/60Hz
Power Consumption:
- 9.5W(max power consumption)
Dimensions ( W x D x H ):
- 3.5×1.4×4.9 in. (89×35.0×124.1 mm)
Antenna:
- 2 External Antennas
WIRELESS FEATURES:
Wireless Standards:
- IEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz
Frequency:
- 2.4GHz & 5GHz
Signal Rate:
- 5GHz:Up to 867 Mbps
- 2.4GHz:Up to 300Mpbs
Reception Sensitivity:
2.4G:
- 11g 54Mbps: -78dBm, 11n HT20 MCS7: -76dBm
- 11n HT40 MCS7: -74dBm
5G:
- 11a 6Mbps: -94dBm, 11a 54Mbps: -77dBm
- 11ac HT20 MCS0: -94dBm, 11ac HT20 MCS8: -71dBm
- 11ac HT40 MCS0: -92dBm, 11ac HT40 MCS9: -66dBm
- 11ac HT80 MCS0: -87dBm, 11ac HT80 MCS9: -62dBm
Wireless Modes:
- Range Extender/Access Point
Wireless Functions:
- Enable/Disable Wireless Radio, Wireless Statistics
Wireless Security:
- 64/128-bit WEP, WPA/WPA-PSK2/WPA2-PSK2 encryptions
Transmission Power:
- 2.4 GHz ≤20dBm, 5 GHz ≤30dBm
Warranty: 1year
