Description
AC10
AC1200 Wireless Dual Band Router
- High-Speed Wi-Fi– Stream with fast and stable connections, reaching speeds up to 1167 Mbps (300 Mbps on the 2.4 GHz band and 867 Mbps on the 5 GHz band)
- 4 High-Gain External Antennas– Receive strong Wi-Fi signals in every corner of your home
- Easy Installation– Set up in minutes guided by an intuitive web UI
- Active Parental Controls – Protect your family by setting appropriate access policies for responsible, safe internet use
- Multi-Mode— Access Point Mode, Range Extender Mode, and Router Mode supported to satisfy all application scenarios
- IPTV and IPv6 Supported
Wireless:
- Wireless Standards :IEEE 802.11ac/n/a 5 GHz, IEEE 802.11b/g/n 2.4 GHz
- Frequency: 2.4 GHz, 5 GHz
- WiFi Speeds: Up to 300 Mbps on 2.4 GHz, 867 Mbps on 5 GHz
Reception Sensitivity:
- 11g 6Mbps: -96dBm
- 11g 54Mbps: -78dBm
- 11n HT40 MCS7: -74dBm
- 11n HT20 MCS7: -71dBm
- 11a 6Mbps: -97dBm
- 11a 54Mbps: -79dBm
- 11ac VHT20 MCS8: -74dBm
- 11ac VHT40 MCS9: -70dBm
- 11ac VHT80 MCS9: -65dBm
Transmission Power:
- 2.4 GHz < 20dBm (EIRP)
- 5 GHz < 23dBm (EIRP)
Wireless Security:
- WEP
- WPA / WPA2-Personal
- WPA2 / WPA3-Personal
Wireless Functions: Enable/Disable Wireless Radio, WMM
Software:
- Operation Modes:Router Mode, Access Point Mode
- WAN Type: Dynamic IP/Static IP/PPPoE/L2TP/PPTP
- Management: Access Control, Local Management, Remote Management
- DHCP: Server, DHCP Client List
- NAT Forwarding: Port Forwarding, Port Triggering, UPnP, DMZ
- Firewall Security: SPI Firewall, IP and MAC Address Binding
- Guest Network: 2.4 GHz Guest Network, 5 GHz Guest Network
Hardware:
- Dimensions: 4.5 × 3.7 × 1.0 in (114 × 94 × 26 mm)
- Interfaces: 1× 10/100 Mbps WAN Port / 2× 10/100 Mbps LAN Ports
-
Button: Reset/WPS Button
-
External Power Supply: 9V/0.85A
-
Antenna Type: 4× 5 dBi Fixed Omni-Directional Antennas
Warranty: 1YEAR
