AC1200 Wireless Dual Band Router

• High-Speed Wi-Fi– Stream with fast and stable connections, reaching speeds up to 1167 Mbps (300 Mbps on the 2.4 GHz band and 867 Mbps on the 5 GHz band)
• 4 High-Gain External Antennas– Receive strong Wi-Fi signals in every corner of your home
• Easy Installation– Set up in minutes guided by an intuitive web UI
• Active Parental Controls – Protect your family by setting appropriate access policies for responsible, safe internet use
• Multi-Mode— Access Point Mode, Range Extender Mode, and Router Mode supported to satisfy all application scenarios
• IPTV and IPv6 Supported

Wireless:

• Wireless Standards :IEEE 802.11ac/n/a 5 GHz, IEEE 802.11b/g/n 2.4 GHz
• Frequency: 2.4 GHz, 5 GHz
• WiFi Speeds: Up to 300 Mbps on 2.4 GHz, 867 Mbps on 5 GHz

Reception Sensitivity:

• 11g 6Mbps: -96dBm
• 11g 54Mbps: -78dBm
• 11n HT40 MCS7: -74dBm
• 11n HT20 MCS7: -71dBm
• 11a 6Mbps: -97dBm
• 11a 54Mbps: -79dBm
• 11ac VHT20 MCS8: -74dBm
• 11ac VHT40 MCS9: -70dBm
• 11ac VHT80 MCS9: -65dBm

Transmission Power:

• 2.4 GHz < 20dBm (EIRP)
• 5 GHz < 23dBm (EIRP)

Wireless Security:

• WEP
• WPA / WPA2-Personal
• WPA2 / WPA3-Personal

Wireless Functions: Enable/Disable Wireless Radio, WMM

Software:

• Operation Modes:Router Mode, Access Point Mode
• WAN Type: Dynamic IP/Static IP/PPPoE/L2TP/PPTP
• Management: Access Control, Local Management, Remote Management
• DHCP: Server, DHCP Client List
• NAT Forwarding: Port Forwarding, Port Triggering, UPnP, DMZ
• Firewall Security: SPI Firewall, IP and MAC Address Binding
• Guest Network: 2.4 GHz Guest Network, 5 GHz Guest Network

Hardware:

• Dimensions: 4.5 × 3.7 × 1.0 in (114 × 94 × 26 mm)
• Interfaces: 1× 10/100 Mbps WAN Port / 2× 10/100 Mbps LAN Ports
• Button: Reset/WPS Button

• External Power Supply: 9V/0.85A

• Antenna Type: 4× 5 dBi Fixed Omni-Directional Antennas


Warranty: 1YEAR
