Description
MWE Bronze 750 V3
- ATX 3.1 support
- High temperature resilience
- Quiet HDB fan
- 80 Plus Bronze certified efficiency
- Embossed cable
Specifications
- Model :MPE-7501-ACAAW-3B
- ATX Version :ATX 12V Ver. 3.1
- PFC :Active PFC
- Input Voltage :100-240V
- Input Current :10-6A
- Input Frequency :50-60Hz
- Dimensions (L x W x H) :140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch
- Fan Size :120mm
- Fan Bearing :HDB
- Efficiency :>85% @ Typical Load
- 80 PLUS Rating :80 PLUS Bronze
- ErP 2014 Lot 3 :Yes
- Operating Temperature :0-40°C
- Power Good Signal :100 - 150 ms
- Hold Up Time :>16ms
- MTBF :>100,000 Hours
- Protections :UVP / OVP / OPP / OTP / SCP
- Regulatory :cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (Based on region's requests.)
- ATX 24 Pin Connectors :1
- EPS 8 Pin / 4+4 Pin Connectors :2
- SATA Connectors :6
- Peripheral 4 Pin Connectors :3
- PCI-e 6+2 Pin Connectors :4
- Series :MWE Bronze Series
- Category :500 to 750W
- Modular :Non Modular
- 80 Plus Efficiency :Bronze
- Form Factor :ATX
- Watts :750W
- warranty : 1 year
