Description
ACCESS POINT 4PORT TP-LINK ARCHER C24 AC750 (4Antenna) :
Description
- High-Speed Wi-Fi—AC750 dual-band is ideal for HD video streaming, high-speed downloading.
- Far-Reaching Coverage—4× antennas deliver far-reaching Wi-Fi and reliable connections.
- Multi-Mode 3 in 1—Supports Router, Access Point, and Range Extender to add flexibilities.
- Parental Controls—Manages when and how connected devices can access the internet.
- Guest Network—Provides separate access for guests while securing the host network.
- Smooth HD Streaming—Supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV streaming.
- IPv6 Supported—Compatible with the IPv6 (the latest Internet Protocol version 6).
- Compact and Mountable—Designed to conserve space and complement any décor.
Specifications
WIRELESS:
- Standards: Wi-Fi 5: IEEE 802.11ac/n/a 5 GHz
- IEEE 802.11n/b/g 2.4 GHz
- WiFi Speeds: AC750: 5 GHz: 433 Mbps (802.11ac)
- 2.4 GHz: 300 Mbps (802.11n)
- WiFi Range:
- 2 Bedroom Houses: (4× Fixed Antennas):
- Multiple antennas form a signal-boosting array to cover more directions and large areas
- WiFi Capacity: Medium: Dual-Band: Allocate devices to different bands for optimal performance
- Working Modes:
- Router Mode
- Access Point Mode
- Range Extender Mode
HARDWARE:
- Processor: Single-Core CPU
- Ethernet Ports:1× 10/100 Mbps WAN Port
- 4× 10/100 Mbps LAN Ports
- Buttons: WPS/Wi-Fi Button
- Power: 9 V = 0.6 A
SECURITY:
- WiFi Encryption:
- WEP
- WPA
- WPA2
- WPA/WPA2-Enterprise (802.1x)
- Network Security:
- SPI Firewall
- Access Control
- IP and MAC Binding
- Application Layer Gateway
- Guest Network:
- 1× 2.4 GHz Guest Network
- 1× 5 GHz Guest Network
SOFTWARE:
- Protocols:
- IPv4
- IPv6
- Parental Controls:
- URL Filtering
- Time Controls
- WAN Types:
- Dynamic IP
- Static IP
- PPPoE
- PPTP
- L2TP
- Quality of Service: QoS by Device
- NAT Forwarding:
- Virtual Servers
- Port Forwarding
- Port Triggering
- UPnP
- DMZ
- IPTV:
- IGMP Proxy
- IGMP Snooping
- Bridge
- Tag VLAN
- DHCP:
- Server
- DHCP Client List
- Address Reservation
- DDNS:
- NO-IP
- DynDNS
- Management:
- Tether App
- Webpage
TEST DATA:
- WiFi Transmission Power: CE: <20dBm(2.4GHz) <23dBm(5GHz)
- WiFi Reception Sensitivity: 5 GHz:
- 11a 54M: -76dBm;
- 11ac VHT20 MCS8: -71dBm;
- 11ac VHT40 MCS9: -66dBm;
- 11ac VHT80 MCS9: -62dBm
- 2.4 GHz:
- 11g 54M: -76dBm;
- 11n HT20 MCS7: -73dBm;
- 11n HT40 MCS7: -71dBm
PHYSICAL:
- Dimensions (W×D×H):4.5 × 4.2 × 1.0 in(115 × 106.7 × 24.3 mm)
- Warranty: 1year
