Description
Specifications
- Brand: Hikvision
- Model: DS-7104HGHI-M1(C)
- Type: DVR
-
Video & Audio
- IP Video Input: 1-Ch (up to 5-ch) Enhanced IP Mode On: 2-Ch (Up to 6-ch), Each Up to 4 Mbps Up to 6 MP Resolution Support H.265+/H.265/H.264+/H.264 IP Cameras
- Analog Video Input: 4-Ch BNC Interface (1.0 Vp-p, 75 Ω), Supporting Coaxitron Connection
- Video Live: 1080P
- Video Recording: 720P
- Video Input Types: HDTVI/AHD/CVI/CVBS/IP
- VGA Output: 1-Ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- HDMI Output: 1-Ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- Audio Input: 1-Ch (up to 4-Ch is Optional), RCA (2.0 Vp-p, 1 KΩ), 4-Ch via Coaxial Cable
- Audio Output: 1-Ch, RCA (Linear, 1 KΩ)
-
Recording
- Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Frame Rate: Main Stream: When 1080p Lite mode not enabled: 3K, lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps For 5 MP, enabled: 3K lite/5 MP lite@12fps;4 MP, Sub-stream: WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)
- Video Bitrate: 32 Kbps to 6 Mbps
- Stream Type: Video, Video & Audio
- Audio Bitrate: 64 Kbps
-
Network
- Network Interface: 1x RJ45 10/100 Mbps self-adaptive Ethernet interface
- Total Bandwidth: 72 Mbps
- Remote Connection: 32
-
Interface
- HDD Type: 1x SATA
- Capacity: Up to 10TB Capacity for Each Disk
- USB: Rear Panel: 2× USB 2.0
-
General
- Operating Temperature: -10 °C to +55 °C (+14 °F to +131 °F)
- Operating Humidity: 10% to 90%
- Power Supply: 12 VDC, 1.5 A
- Power Consumption: ≤ 8 W
- Dimensions (W × D × H): 200 x 200 x 48mm
-
Warranty: 1 Year
