Description
Specifications
- Architecture: Raptor Lake
- Socket: LGA 1700
- Cores / Threads: 10 Cores (6P+4E) / 16 Threads
-
Base Clock:
- Performance Cores: 2.5 GHz
- Efficient Cores: 1.8 GHz
-
Max Turbo Clock:
- Overall: 4.7 GHz
- Performance Cores: 4.7 GHz
- Efficient Cores: 3.5 GHz
-
Cache:
- L2: 9.5MB
- L3: 20MB
- Manufacturing Process: Intel 7
-
Memory Support:
- DDR4 3200 / DDR5 4800
- Dual Channel
- Max Capacity: 192GB
- Max Bandwidth: 76.8 GB/s
- PCIe Support: PCIe 5.0 / 4.0 (Up to 20 Lanes)
-
TDP:
- Base: 65W
- Max Turbo: 148W
- Integrated Graphics: None
- Cooler: Intel Laminar RM1 (Included)
- Supported Chipsets: H610, H670, B660, Q670, W680, Z690, H770, B760, Z790 (BIOS update may be required for older motherboards)
- OS Compatibility: Windows 10 (22H2, 21H2), Windows 11 (22H2, 21H2), Linux
- Warranty : 1 year
