Description
Specifications
- Model : CS-CP1-R105-1L2WF
- Image sensor : 1/3" Progressive Scan CMOS
- Shutter Speed :Self-adaptive shutter
- Lens : 4mm @ F1.6, view angle: 90°(Diagonal), 80° (Horizontal), 43°(Vertical)
- Lens Mount : M12
- Day & Night : IR-cut filter with auto switch
- DNR :3D DNR
- WDR : Digital WDR
- Compression
- Video Compression : H.264/H.265
- Video Bit Rate : Adaptive bit rate.
- Image
- Max. Resolution : 1920 × 1080
- Frame Rate : Max:25fps; Self-Adaptive during network transmission
- Network
- Smart Alarm: Motion Detection, Human Shape Detection, Loud Noise Detection, Patrol Mode Detection
- Wi-Fi Pairing : AP paring
- Protocol: EZVIZ cloud proprietary protocol
- Interface Protocol : EZVIZ cloud proprietary protocol
- Interface
- Storage: Micro SD card slot (Max. 512G)
- Power:TYPE-C
- Wired Network : Not support
- Wi-Fi
- Standard : IEEE802.11a, 802.11b, 802.11g, 802.11n
- Frequency Range : 2.4G: 2400~2483.5MHz
- Channel Bandwidth :Supports 20MHz
- Security :WPA/WPA2, WPA-PSK/WPA2-PSK
- Transmission Rate :11b 11 Mbps, 11g 54 Mbps, 11n: 72 Mbps
- Output Power(EIRP) : 19 dBm
- Antenna Gain : 1.9 dBi
- General
- Operating Conditions : -10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing)
- Power Supply: DC 5V/1A
- Power Consumption : MAX. 5W
- IR Range: MAX. 10 meters(32.81ft)
- Dimensions: 88mm x 88.2 mm x 119mm (3.46” x 3.47” x 4.69”)
- Packaging Dimensions :103mm x 103mm x 168mm (4.06” x 4.06” x 6.61”)
- Bare Weight : 222 g (0.49 lb)
- warranty : 1 year
