Description
Product Features
- Auto power-down disables unused ports
- Smart power for short cable runs
- Port status switch to control lights
- Wired connection speeds up to 1000 Mbps
- Complies with the IEEE 802.3, 802.3u, 802.3x, 802.3ab, and 802.3az standards
- Non-blocking 48 Gbps switching capacity ensures maximum throughput
- Wired connection speeds up to 1000 Mbps on all ports
- Supports Jumbo Frames for improved data transfer efficiency
- Fanless design for silent operation
Specifications
Hardware
- Ports: 24 Ethernet ports
- Power: 100 V - 240 V 50/60 Hz Internal
- Rack-mountable
- Weight: 2290 g
- Operating Temperature: 0°C to 50°C (32°F to 122°F), 10 to 90% Relative Humidity (non-condensing)
- Storing Temperature: -40°C to 70°C (-40°F to 158°F), 10 to 90% RH (non-condensing)
- Dimensions:
- V1: 440 mm × 200 mm × 44 mm
- V2: 440 mm × 201 mm × 44 mm
Indicator Light
- System Indicator Light
- Solid Blue: Normal operation
- OFF: Power is OFF
- Front Network Indicator (Link / Activity / Speed)
- Solid Green: 1 Gbps link
- Flashing Green: 1 Gbps activity
- Solid Orange: 10/100 Mbps link
- Flashing Orange: 10/100 Mbps activity
- OFF: No connection
- warranty : 1 year
