Description
MAG A750GL PCIE5
- ATX 3.1 ready, native PCIe 5.1 dual-color 16-pin cable
- Supports NVIDIA® GeForce RTXTM 40 Series graphics cards
- Full modular design,Flat cables
- 80 Plus Gold certified for high efficiency
- Active PFC design,Industrial level protection with OVP,OCP,OPP,OTP, SCP,UVP
- 120mm Fluid Dynamic Bearing Fan
- LLC Full Bridge Topology with DC-DC
module design
Specifications
- Efficiency Rating: 80 PLUS Gold (up to 90%)
- Modular: Yes (full modular)
- Fan Size :120 mm
- Fan Bearing :Fluid Dynamic Bearing
- Dimensions (DxWxH) :140 x 150 x 86 mm
- PFC Type :Active PFC
- Input Voltage Range :100~240 VAC
- Power Watt :750W
-
Power Excursion: 1500W (*up to 200% of the PSU's rated power for
100μs) - Input Frequency Range :47-63Hz
- Protection: OCP / OVP / OPP / OTP / SCP / UVP
- ATX (24 pin): 1
- EPS (4+4 pin) :2
- PCI-E 5.0 (16 pin): 1 (450W)
- PCI-E (6+2 pin): 3
- SATA (15 pin) :8
- MOLEX (4 pin) :4
- FDD (4 pin) :1
- warranty: 1 year
