Description
Specification
- Performance Parameters
- Light Sources :Red LED
- Supported symbologies
- 1D:Codabar,Code 39,Code 32Pharmaceutical(PARAF),Interleaved 2 of5,NEC 2 of 5, Code 93, Straight 2 of 5 lndustial,Straight 2 of 5 lATA, Matrix 2 of5,Code 11,Code 128,GS1-128,UPC-A,UPC-E,EAN/JAN-8,EAN/JAN-13,MSl, GS1 DataBar-Omnidirectional,GS1 DataBar Limited, GS1 DataBar Expanded China Post(Hong Kong 2 of 5), Korea Post.
2D:PDF417,Micro PDF417,QR Code,Data Matrix,MaxiCode,Aztec,HanXin,Codeblock A, Codeblock F,GS1 Composite Codes. - lmage Sensor 640 pixels(H)x480 pixels(V)
- Scan Mode Automatic Induction Scanning
- Precision ≥4mil(Code39)
- Scan Angel 13mil (EAN13) 20mm-200mm
- Support Keyboard Support multiple languages (multiple language special characters)
- Print Contrast 20% minimum reflective difference
- Recognition angle range Turn +360°,Elevation +65°, Declination ±65°
- System compatibility Linux,Android,Windows,lOS
- Human-computer Interaction LED light circle indication, buzzer indication
- Interface USB-KBW, USB-COM, RS232
- Physical Parameters
- Dimensions 96.8mm*79mm*151.4mm
- Weight 260g
- Material ABS+PC
- Cable Length 1.8m
- Environmental Parameters
- Operating Temperature 20℃ ~ 55℃
- Storage Temperature -20℃ ~ -60℃
- Humidity 5%-95% RH (Non-condensing/non-freezing)
- Ambient Light 0-100000LUX
- Shock Resistance Withstands multiple 1.5m drops to concrete
- Electrical Parameters
- Voltage DC5V ±5%
- Electric current 210mA(Operating)
- warranty : 1 year
